Products100W Portable Foldable Solar Panel for Power Stations
50wsolarpanel1
glass solar panelSolar Panel

100W Portable Foldable Solar Panel for Power Stations

100W Compact: High power, slim frame. Pro Build: Weatherproof premium materials. Max Yield: Advanced cells, high conversion. Tough Body: Handles wind and snow. Easy Fit: Fast, pre-drilled setup.

Contact Us

Product Description

Lightweight, compact, and designed for the ultimate outdoor adventure.
This 100W(2pcs*50watt) foldable solar panel directly charges your portable solar generators and power stations, keeping your essential gear running while camping or off the grid.

Product Features

  • High Conversion Rate: Premium monocrystalline cells offering up to 23.4% efficiency.
  • Water & Dust Resistance: IP68 waterproof rating, perfect for unpredictable weather.
  • Adjustable Kickstand: Built-in stand allows you to adjust the angle from 0-180 degrees to maximize sunlight absorption.
  • Universal Compatibility: Comes with standard MC4 connectors, compatible with most third-party solar generators.
  • High Conversion Rate: Premium monocrystalline cells offering up to 23.4% efficiency.
  • Water & Dust Resistance: IP68 waterproof rating, perfect for unpredictable weather.
  • Adjustable Kickstand: Built-in stand allows you to adjust the angle from 0-180 degrees to maximize sunlight absorption.
  • Universal Compatibility: Comes with standard MC4 connectors, compatible with most third-party solar generators.


Specifications


Specifcations
Output Cables: 1.2m
Connectors: Solar Connectors
Maximum Power: 50W
Maximum System Voltage: 600V DC (UL)
Optimum Operating Voltage (Vmp): 18.6V
Open-Circuit Voltage (Voc): 22.3V
Optimum Operating Current (Imp): 2.69A
Short-Circuit Current (Isc): 2.94A
Weight: 2.8 kg
Dimensions: 650*400*25mm
Operating Temperature:  -40°F to 194°F(-40°C to +90°C)
Panel Leads (Pair): 14AWG (1.2 mv long)
Warranty: 5-year output warranty & material and workmanship warranty
Performance: 5 year 95% output warranty 10 year 90% output warranty 25 year 80% output warranty
Built-in Components
Junction Box: IP65
Solar Connectors: IP67
Panel Leads (Pair):14AWG
